48VAC 4-Wire Miniature Slip Ring 1A Current 100 RPM Speed
Premium Products
48VAC 4-Wire Miniature Slip Ring 1A Current 100 RPM Speed
1
2
Place of Origin :Guangdong, China
Brand Name :JINPAT
Model Number :LPMS-04A
MOQ :1
Price :$18.50
Circuit Number :4
Current Rating :1A
Voltage :48VAC
Working Speed :0~100 rpm
Working Temperature :-20~+60℃
Electrical Noise :≤15mΩ
Contact Material :Precious metal
Housing Material :Stainless steel
Wire Size :30# silver plated copper UL, Teflon
Lead Wire Length :Rotor:250mm; Stator:250mm
Protection Grade :IP54
Style :Capsule slip ring
Type :Electronic Accessories
Contact Type :Gold contacts
Wire Color :Color-coded
Contact Now
Bargain Price Only in Alibaba
Description
The LPMS-04A super miniature slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary part to a rotating part.
The LPMA-04A unit is a standard, off-the-shelf unit that uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical connections.
A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.
Signal Slip rings (USB2.0/USB3.0 slip ring,fiber optic rotary joint,high frequency slip ring,etc)
Pneumatic/Hydraulic Rotary Unions
Custom Slip Rings
Large volume series
4. How do I choose a slip ring?
Proper selection of a slip ring solution requires details about your application’s operating parameters including total circuits, voltage and amps per circuit, operating speed, and mounting type. If you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started.
5. Do you offer custom slip rings?
Yes, if you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started. Our engineers will come up with perfect solution for your needs.
